Mracking Medium Duty Warehouse Rack Adjustable Storage Racks and Shelves Selective Pallet Steel Rack Wholesale Sale
Product Description
Product Description
Medium Duty Rack:
Medium duty rack belongs to warehouse storage racking systems. It can be adjusted by each 50mm, and the load capacity can reach 200~500kg. The beam is "P" type beam, whose height matches with that of the layer board.
| Standards Size | Layer | Loading Weight | Beam (mm) | Upright (mm) | Thickness of Board (mm) |
|---|---|---|---|---|---|
| L2000*D600*H2000 | 4 | 200~300kg/layer | 60*40*1.2 | 60*50*1.2 | 0.5 |
| L2000*D600*H2000 | 4 | 400~500kg/layer | 60*40*1.5 | 60*50*1.5 | 0.7 |
| Product Name | Medium Duty Rack/Shelf |
| Material | High-Quality Q235 Cold-Rolled Steel |
| Loading Capacity | 200~500kgs/level |
| Thickness | Upright: 60*40*1.0, 1.2, 1.5mm | Beam: 60*40 / 80*40*1.0, 1.2, 1.5mm | Steel: 0.5, 0.6, 0.7mm |
| Color | Upright: Blue, Beam: Orange, Steel: Gray white. (Customizable in any color) |
| Surface Treatment | Electrostatic Spray Surface |
| Packing Term | Air bubble, Carton, Wooden Case |
| Warranty | 10 Years |
| Certification | SGS |
1
Long span shelving rack is very convenient for installation.
2
The adjustment distance of steel layers is 50mm for multiple usages. It consists of vertical columns, layer plates, corner pieces, pins, special bolts and plastic footing.
3
The surface is electrostatic sprayed and color is selectable. It provides superior anti-corrosion and rust protection performance.
4
Widely applied across family storage, retail stores, supermarkets, commercial company warehouses, and public institutions.
Beam Loading Capacity & Size
Detailed Images
| Medium Duty Rack Specifications | |
|---|---|
| Size | L2000*D600*H2000mm, Loading: 300kg/layer, Layer: 4 levels |
| Material | Upright: 60*50*1.0, Beam: 60*40*1.2, Steel: 0.5mm |
| Color | Upright is blue, beam and steel is gray white |
| Packaging Term | Air bubble |
| Surface treatment | Powder Coating |
Beam & Upright Connect
Diagonal & Horizontal Bracing Installed
Steel Board Section
Product Overviews
Hot Sale Products
Heavy Duty Pallet Racking
Medium Duty Rack
Mould Rack
Cantilever Rack
Mezzanine Floor
Wire Mesh Container
Frequently Asked Questions (FAQ)
Q1Are you a manufacturer or trading company?
AWe are a professional racking manufacturer located in Dongguan, Guangdong.
Q2What is the material used for the racks?
AOur products are made of high-quality Q235B cold rolled steel.
Q3What is the standard delivery time?
AGenerally less than 15 workdays. The exact delivery timeline also depends on the order quantity and shelving design.
Q4What are the payment terms?
AWe accept 30% T/T down payment and 70% T/T balance before delivery.
Q5How can I get a quick quotation for my racking project?
A
For a quick and precise quotation, please share the following details:
- Dimensions of the rack: Length * Depth * Height
- Number of layers per set
- Loading capacity per beam layer
- Required racking quantity
Q6Are samples available, and what is your quality control standard?
AYes, we offer free samples with freight collected. Quality is our highest priority, backed by ISO 9001 2001 and SGS certifications.
