Every rack system manufactured by Guangzhou Heda Shelves Co., Ltd. is cold-formed from high-tensile structural steel, pretreated with pickling and phosphating, and coated with electrostatic powder to prevent corrosion in demanding industrial environments.
SYS 01 A specialized high-density evolution of selective racking designed for aisle widths down to 1.5–1.8m. Guided by floor rails or inductive wire systems, VNA racks utilize full clear ceiling height up to 18m while maintaining 100% direct pallet accessibility.
SYS 02 Engineered cradle and saddle structures specifically designed for cylindrical products such as textile rolls, paper mill reels, coiled wires, and plastic films. Prevents point-load roll damage and stabilizes materials during forklift access.
SYS 03 The global benchmark for multi-SKU inventory management. Provides uninhibited 100% direct access to every pallet position. Compatible with standard counterbalance and reach trucks across FMCG, retail, automotive, and manufacturing warehouses.
SYS 04 High-density block storage eliminating picking aisles by allowing forklifts to drive directly into deep lane racks. Designed for Last-In-First-Out (LIFO) or First-In-First-Out (FIFO) operations with large volumes of uniform SKUs, ideal for cold chain facilities.
SYS 05 Dynamic live storage equipped with inclined roller tracks and centrifugal speed controllers. Pallets loaded from the loading aisle roll smoothly to the front picking face by gravity, ensuring automatic and strictly disciplined FIFO stock turnover.
SYS 06 A semi-automated high-density storage solution where autonomous battery-powered shuttle carts retrieve and deposit pallets within deep storage channels. Protects racking from forklift collisions and drastically reduces warehouse cycle times.
SYS 07 Engineered without front upright obstructions to handle long, awkward, and bulky materials including structural steel beams, plastic and steel piping, timber packs, and gypsum boards. Modular arms allow flexible horizontal spacing.
SYS 08 Nested rolling carts resting on inclined structural steel channels deliver 2 to 5 deep pallet storage per lane. Pallets are loaded from a single aisle by pushing previous pallets back, creating high density without forklifts entering the rack frame.
Guangzhou Heda Shelves Co., Ltd. eliminates project uncertainty by offering complimentary design, layout verification, and structural load calculations before any steel is rolled.
Provide your warehouse dimensions, column grid, and door clearances. Our senior logistics engineers deliver an optimized AutoCAD floor plan within 72 hours, optimizing forklift turning radiuses and pallet bay counts.
Visualize clearance heights, pallet clearances, lighting corridors, and picking walkways with high-resolution 3D models before equipment installation, minimizing architectural clashes.
Every proposal includes verified base plate load distributions, upright column gauges, and anchor bolt specifications aligned with regional building codes and site slab properties.
Combining 25+ years of production experience with rigorous quality control, Guangzhou Heda Shelves Co., Ltd. delivers engineered racking solutions to over 120 countries worldwide.
Manufacturing heavy-duty steel storage systems since 2001 across industrial, FMCG, and automotive sectors.
Automated roll-forming, continuous punching, and robotized welding guarantee large-scale volume shipments on time.
Fully compliant with international EN structural racking standards and European CE-CPR certification.
Proven track record implementing complex automated, cold store, and multi-tier mezzanine installations globally.
Proven storage solutions delivered to logistics centers, manufacturing facilities, and heavy supply yards.
Reinforced beam profiles, barrel cradles, and heavy-duty wire mesh decking designed for high-density chemical barrel storage in harsh ambient environments.
A multi-tier picking platform utilizing heavy pallet rack frames as structural building supports, doubling usable square footage without new construction.
Engineered with staircase accesses, pallet safety drop gates, and heavy longspan shelving bays to organize over 15,000 distinct automotive repair parts.
Clear technical answers addressing specification, load tolerances, safety, and operational considerations.
Single-sided systems feature arms extending from one face of the upright tower, engineered for perimeter walls or one-way service lanes. Double-sided systems utilize a central upright tower with cantilever arms extending from both front and back faces, doubling storage density on a shared foundation.
Capacities range from 200 kg for light-duty manual storage up to 3,000 kg per arm for heavy steel bars, structural tubes, and industrial machinery components. Load capacity is governed by arm length, profile steel gauge, and attachment connection pins.
Yes. All uprights and columns produced by Guangzhou Heda Shelves Co., Ltd. are punched at continuous precision pitches (typically 50mm, 75mm, or 100mm), allowing beams and arms to be repositioned without cutting or welding as your load dimensions change.
VNA systems require dedicated wire-guided or mechanical rail-guided turret trucks (man-up or man-down) or articulated forklifts. Aisle widths are customized based on the precise track radius and mast clearance of your handling fleet.
Yes. Guangzhou Heda Shelves Co., Ltd. applies multi-stage pickling and phosphating electrostatic powder coating or Hot-Dip Galvanizing (HDG) to ensure durable corrosion resistance in high-humidity coastal and open outdoor storage yards.
Submit your building dimensions, clear height, and pallet specifications. Our engineers will deliver structural calculations, layout drawings, and containerised CIF quotations within 24 hours.
